Vaisala HMP228 User Manual
Page 14
HMP228
Operating Manual
8
•
STEP 2: open the ball valve assembly
R1/2 ISO 7/1
53
.6
ø5.5
a
d
ju
s
tm
e
nt
r
a
ng
e 12
0m
m
14
8
ø14
(40)
> ш14
ш12
~8
.5
~22
.5
sintered
filter
moisture
sensor
O-ring
wedge
ring
nut
(AV=27mm)
screw A
process pipe or chamber
Figure 2.2.3.3
Installing the probe through the ball valve
assembly; step 2 (measures in mm)
The clasp nut is tightened manually prior to opening the ball valve assembly.
