40

After setting up your OutBack Parallel Stacking and establishing the Master and Slave order, shut off all

the AC input and output breakers and check your system via the following MATE screens:

ADV/FX/STACK---------P04

stack OB Slave L1

phase

DOWN INC DEC PORT

ADV/FX/STACK---------------

stacking setup

completed

TOP ADV MAIN

ADV/FX/STACK---------P04

power save level 3

slave adjust only

DOWN INC DEC PORT

From the ADV/FX/STACK power save level slave adjust only screen, press the soft key, the
soft key, and then the soft key.

ADV/FX/STACK---------P04

power save level 2

master adjust only

DOWN INC DEC PORT

ADV/FX/STACK---------P04

power save level 1

master adjust only

DOWN INC DEC PORT

ADV/FX/STACK----------P04

power save level 0

master adjust only

DOWN INC DEC PORT

Verify this is the power save level
master adjust only screen. Press
the soft key until P01
appears on the screen. Turn on all
of your FX AC Output breakers.
The Master FX’s “INVERTER” LED
should be solid and all the Slaves
“INVERTER” LED’s should be
blinking.

Press the soft key to adjust
the “power save level master adjust
only” from 0 to 1 and watch the
1st Slave’s “INVERTER” LED go solid.
When the “INVERTER” LED is on
solid, this means that the inverter
is on. When the “INVERTER” LED on
the Slave is blinking, this means the
FX is asleep.

Press the soft key once
to adjust the power save level
master adjust only to 2 and
watch the 2nd Slave’s “INVERTER”
LED turn on

ADV/FX/STACK---------P01

power save level 0

master adjust only

DOWN INC DEC PORT

ADV/FX/STACK---------P01

power save level 3

master adjust only

DOWN INC DEC PORT

Press the soft key once to
adjust the power save level master
adjust only to 3 and watch the
3rd Slave’s “INVERTER” LED turn
on. If the system has more than
three Slaves, keep increasing the
value in the power save level master
adjust only
screen and verify that
each Slave’s “INVERTER” LED comes
on as expected. This check verifi es
all FXs are stacked correctly.

Adjust the power save level
master adjust only to 0 by
pressing the soft key.
