Outback Power Systems VFX Series Programming Manual User Manual
Page 36

35
NOTE: If you are doing OutBack Stacking, turn on the FW-X240 Auto Transformer breaker now. Otherwise, go
to the next step.
• Verify the AC voltage output through the MATE following path:
PATH
MAIN---------------------
STATUS------------ STATUS/FX/PAGE1-------
Float P00
STATUS/FX/METER—P00
12.15:30p
choose device:
choose category:
inv 0.0Kw zer 0.0kw
output 117 vac
chg 0.0kw buy 0.0kw
voltage
SUM STATUS SETUP ADV FX CC DC MAIN MODES METER BATT PG2
DOWN STATUS PORT
DOWN UP TOP PORT
BYPASS
OUTPUT
INPUT
With the programming
completed, turn the AC output
breakers ON with the AC
BYPASS on the AC breaker panel
switched to NORMAL.
