ADV/FX/CHARGER---------P00

equalize 14.6 vdc
set point

DOWN INC DEC PORT

ADV/FX/CHARGER---------P00

equalize 01.0 hrs
time period

DOWN INC DEC PORT

ADV/FX/CHARGER------------
charger programming
competed

TOP ADV MAIN

An occasional equalize charge helps destratify the

batteries for a longer working life. Pressing the

hot key leads to screens that begin the

EQ charging voltage. The equalize set point deter-

mines the recharging voltage, which can range

between 14.0 VDC and 17.0 VDC (consult your

battery manufacturer for a specifi c volage)

using

and

. An equalize re-

charging should be supervised until completed.

Press to continue.

The equalize time period limits the equalizing

recharge time. The timer begins advancing once

the battery voltage exceeds the absorb voltage set

point. When the equalize time period is met, the

recharging stops. It is adjustable between 0 hours

and 24 hours using and . Press

to view the last CHARGER screen.

Pressing returns to the fi rst ADV/FX/

CHARGER screen. Pressing returns to the

ADVANCED screen. Pressing brings up

the MAIN screen.
