Optional auxiliary harness – Ag Leader ParaDyme Cell Modem Booster Kit Installation User Manual
Page 27
Hardware Installation Manual
21
Optional Auxiliary Harness
Optional Auxiliary Harness
1. The Auxiliary Harness is used to connect multiple devices to the roof module such as a USB drive, two serial connections
and 12V devices. The Cell Booster can be powered by the Auxiliary Harness by using an optional Power Adapter cable
(PN: 201-0465-01).
Figure 2-31 Auxiliary Harness (PN: 201-0433-01)
2. Connect the Auxiliary Harness to the 12-pin connector under the GPS receiver.
Figure 2-32 Connect Auxiliary Harness
