12 Cell Booster Kit
Cell Modem Booster Installation Procedure
15. .Figure 2-13 the original cell phone coax cable is shown removed from the roof module. This cable will not be used with
the Cell Booster but it is a good idea to keep it for future use.
Figure 2-13 Removed Cable
16. Route the long coax cable provided in your kit across the roof module. The large connector must be at the Cell Booster end
(left) and the small connector must be at the GPS receiver end (right).
Figure 2-14 Route the Coax Cable
