10

Cell Booster Kit

Cell Modem Booster Installation Procedure

11. Disconnect the larger coax connector shown (on right) to get access to the cell phone coax cable connector (on left).

Figure 2-9

Disconnect Cable

12. Disconnect the cell phone coax cable shown.

Figure 2-10 Disconnect Cell Phone Coax Cable
