Chapter 8 Mounting the NetServer in a Rack
45
Note which rack type you have and follow the instructions for your version.
Table 8-1. The Two Rack Types Compared
Rack Feature Type 1 Type 2
Product Nameplate Hewlett Packard Rack System/E Hewlett Packard HP Systems
Front and Rear Doors Curved Flat
Outside Panels Plastic and Modular Sheet Metal and Full-Length
Column Cross Section
(See Figure 8-3) 5-Cornered 3-Cornered
Marking of EIA Units Numbers Stamped in Metal Triangular Cut Outs
Anti-Tip Foot Extends from Front or Rear Extends from Front Only
Columns Attached to Base Offset from Edge of Base Flush with Edge of Base
You can mount the HP NetServer LH 3r in either the Type 1 rack (HP Rack
System/E) or in the Type 2 rack (HP Rack Systems). The procedures for
mounting are similar, except that there are two different templates included and
the mounting slides fasten to the rear columns differently.
Type 1 and Type 2--Mounting the HP NetServer LH
3r in the Rack
NOTE If you want to put your NetServer into a third-party rack, you
may be able to find relevant documentation on HP's web site at
the following URL:
http://www.hp.com/netserver/servsup
1. First, determine and mark the height at which the NetServer is to be
located in the rack enclosure.
Use the original ordering information to locate where each component
goes in the rack. See Figure 8-4.
If the original ordering information is not available, use HP rack
configuration tools to plan the location of the components.
You can also use the HP NetServer rack configuration tools to make
ordering easier and to automatically check that orders are complete. These
tools can be found on the HP web site. Use the Search function with the
words "rack configuration tools" at the following URL:
http://www.hp.com/go/netserver
