Chapter 2

Controls, Ports, and Indicators

6

Rear Panel Controls, Ports, and Indicators

Refer to Figure 2-2 below to locate features on the NetServer's rear panel:

The Remote Management Port links the NetServer to a console for real-
time diagnosis of system operation.

The Serial B Port is a standard serial port.

The Serial A Port is a standard serial port.

The Parallel Port is a standard parallel port.

The Mouse Port accepts a standard PC mouse.

The Keyboard Port accepts a standard PC keyboard.

The Monitor Port accepts a monitor with up to 1024 x 768 x 256
resolution, with a 60-75Hz video refresh rate. The NetServer contains
1MB of video RAM.

The NetServer comes with two 550W power supplies installed on the left
rear. The optional Redundancy Kit provides a power supply and power
supply cage for installation on the right rear. Since the NetServer only
requires two power supplies to run, installing a third power supply
prevents service interruptions from a single power supply failure. With the
Redundancy Kit installed a new power supply can be hot-swapped in.

The Power Connector accepts a standard power cable to connect the
NetServer with the site AC power source.
