Controller Display Messages

40

MSA1000 Controller User Guide

54 REDUNDANCY
FAILED CACHE
DIMMS MISMATCH

Error

The cache memory

modules on two different

controllers are not the same

size. All cache memory

modules must be the same

size for redundancy to

operate.

Remove the array controller

that has been halted,

replace the cache modules

with the appropriately

sized ones, wait 10

seconds, and then reinsert

the array controller

insuring that it is fully

seated in the chassis.

60 NO CACHE
MODULE FOUND

Error

The array controller

requires at least one cache

module in order to operate.

Either there is not one

present or it has failed.

Remove the failed array

controller, either add a

cache module or replace

the failed one, wait 10

seconds, and then reinsert

it insuring that it is fully

seated in the chassis.

Should the issue persist

please contact HP support.

61 DUAL CACHE
MODULE SIZE
MISMATCH

Error

The array controller has

two cache modules

attached but they are of

different sizes. Both cache

modules must be the same

size.

Remove the failed array

controller, replace one of

the cache modules with a

different one that is of the

correct size, wait 10

seconds, and then reinsert

it, insuring that it is fully

seated in the chassis.

62 CACHE MODULE
# MB

Informational

Displays the size of the

cache module inserted into

the respective cache

module slot.

63 VALID CACHE
DATA FOUND AT
POWER-UP

Informational

Valid host data was found

in the battery backed cache

memory at power up. This

data has been flushed to

the drives.

64 CACHE DATA
LOST BATTERY
DEAD

Error

The battery on the cache

memory was no longer

charged. If there was data

in the cache memory then it

has been lost.

Table 3: LCD Message Descriptions

Message

Type

Description

Action
