MSA1000 Controller

21

MSA1000 Controller User Guide

5. Install the new NiMH battery pack by hooking the top of the battery pack to

the top of the Array Accelerator with the pack held at a 30-degree angle to the
plane of the Array Accelerator board.

See

Figure 9

for an illustration.

Figure 9: Installing the battery pack
