Page 55

Table 14 Business Copy Pop-up Menu Commands of the Pair Operation Window
Command
Feature
Detail
Opens the Detail dialog box that displays detailed information for the selected volume
or pair (see
Paircreate
Opens the Paircreate dialog box, which allows you to create new Business Copy pairs
(see
Pairsplit
Opens the Pairsplit dialog box, which allows you to split Business Copy pairs (see
Pairresync
Opens the Pairresync dialog box, which allows you to resynchronize Business Copy
pairs (see
Pairsplit-E
Opens the Pairsplit-E dialog box, which allows you to suspend Business Copy pairs
(see
Pairsplit-S
Opens the Pairsplit-S dialog box, which allows you to delete Business Copy pairs (see
Change Reserve Opens the Set/Reset Reserve Attribute dialog box, which allows you to set/reset the
Business Copy reserve attribute (see
S-VOL Path
Opens the S-VOL Path dialog box (see
on page 87), which displays the port
or host group of the S-VOL of the selected pair.
Information
Opens the Information dialog box (see
on page 88), which displays the
number of pairs or reserved volumes.
The Preview List
The Preview List (see
on page 55) is located below the Volume List, and lists the specified
operations (volume/pair information) that have not been performed in the storage system.
Figure 25 Preview List Displaying Settings (Operations)
The Preview List displays the following information:
•
P-VOL: Information about P-VOL is displayed in AAA-BB-CCC(XX:YY:ZZ) format.
• AAA: The port ID (cluster and channel number)
• BB:
The
group
number
of
host
group
• CCC: LU number
• XX:YY:ZZ: LDKC number:CU number:LDEV number
Note:
An LDEV number that ends with a # mark indicates that the LDEV is an external volume
(for example, 00:00:01#). An LDEV number that ends with a letter X indicates that the LDEV is
a virtual volume used by XP Thin Provisioning (for example, 00:00:01X). For details regarding
the external volumes, see the HP StorageWorks XP24000 External Storage Software User’s
Guide. For information about XP Thin Provisioning, see the HP StorageWorks XP24000 Thin
Provisioning Software User's Guide.
XP24000 Business Copy Software User's Guide
55
