• Hide Mode: When the S-VOL cannot be read in the mode, N is displayed.
on page 54 shows the S-VOL status, which is indicated by the displayed letters.
Table 12 S-VOL Status Indicated by the SvolMode
S-VOL Write (W) Hide Mode (N)
Letters
OFF
OFF
—
OFF
ON
N
ON
OFF
W
ON
ON
W
•
Copy Pace: The copy pace (Slower, Medium, or Faster) for the pair being created is displayed.
For details about what will be displayed in this item if you select XP Snapshot pairs, see the HP
StorageWorks XP24000 Snapshot User’s Guide.
•
Sync.: The information (as shown in
on page 54) to the pair status is displayed. For
details about what will be displayed in this item if you select XP Snapshot pairs, see the HP
StorageWorks XP24000 Snapshot User’s Guide.
Table 13 Displayed Information in Progress
Pair Status
Displayed Information
SMPL
- - - is displayed.
COPY(PD)
The progress (%) of copying.
PAIR
Identical data (%) of P-VOL and S-VOL.
COPY(SP)
Copy completed data (%).
PSUS(SP)
PSUS
Identical data (%) of P-VOL and S-VOL.
COPY(RS)
COPY(RS-R)
PSUE
- - - is displayed.
SMPL(PD)
•
Emulation: The emulation type of the volume. For details on the kinds of emulation type, see
•
Capacity (MB): The storage capacity of the volume displayed in megabytes (MB).
•
CLPR (P): The cache logical partition of the P-VOL is displayed.
•
CLPR (S): The cache logical partition of the S-VOL is displayed.
You can perform Business Copy operations for the desired volumes in the Volume List, by using the
following pop-up menu commands:
