Troubleshooting
85
Some status messages are available without pressing the F3 key. For example, on
the Main menu, the FAILED status appears next to the logical drive that has
failed. EXPANDING and REBUILDING appear next to the array in which the
activity is occurring.
Handling disk drive failures
If the MSA500 G2 controller was configured with hardware fault tolerance,
complete the following steps after a disk drive failure:
1. Determine which physical drive failed. On hot-plug drives, an amber drive
failure LED illuminates.
2. If the unit containing the failed drive does not support hot-plug drives,
perform a normal shutdown.
3. Remove the failed drive and replace it with a drive that is of the same
capacity. For hot-plug drives, after you secure the drive in the bay, the LEDs
on the drive each flash once in an alternating pattern to indicate a successful
connection. The online LED flashes, indicating that the controller recognized
the drive replacement and began the recovery process.
4. Power up the server, if applicable.
5. The MSA500 G2 controller reconstructs the information on the new drive,
based on information from the remaining physical drives in the logical drive.
While reconstructing the data on hot-plug drives, the online LED flashes.
When the drive rebuild is complete, the online LED is illuminated.
NetWare cannot detect a single physical drive failure when using hardware-based
fault tolerance; NetWare determines that the data is still valid and accessible
during the rebuilding process. However, the driver knows that a physical drive
has failed. A message is printed on the console notifying the user that a physical
drive is in a degraded state. CPQONLIN also shows that the drive has failed.
Display messages
List of messages:
Box numbering .............................................................................................................................
