Component

identification

23

Bay

SCSI ID

Bus Port

5 4

0

6 5

0

7 8

0

8 0

1

9 1

1

10 2

1

11 3

1

12 4

1

13 5

1

14 8

1

Hot-plug SCSI hard drive LEDs

Item LED

description

Status

1

Activity status

On = Drive activity

Flashing = High activity on the drive or drive
is being configured as part of an array.

Off = No drive activity
