Setup 45

Item Description

3 Servers

4

Ethernet crossover cable

NOTE: The ethernet crossover cable is for Microsoft® and Linux
operating systems only.

Single-server configuration

Item Description

1

MSA500 G2 storage system

2

VHDCI SCSI cable

3 Server

SSP hardware configurations

To configure the hardware for SSP, use SCSI cables to connect each server to the
2-Port or 4-Port Shared Storage Module installed in the storage system. Boot
volumes for individual servers can reside on server drives or storage system
drives.
