46 HP StorageWorks MSA500 G2 Storage System User Guide
After choosing the configuration that best suits your needs, enable SSP with
ACU Version 7.10 or later. Locate ACU on the SmartStart CD. For instructions,
refer to the HP Array Configuration Utility User Guide on the Documentation
CD.
Other configurations
For four-node SSP configurations, refer to the documentation that ships with the
4-Port Shared Storage Module.
For multipath software configurations, refer to the HP Smart Array Multipath
Software User Guide that ships with that option.
For more information about these options, refer to the HP website
(
http://www.hp.com/products/sharedstorage ).
Cabling the storage system
After installing the storage system in a rack, connect the SCSI cables and power
cords to the rear panel.
SCSI cabling guidelines
Always be sure that the servers attached to the storage system are powered down
and power cords are disconnected before connecting SCSI cables.
IMPORTANT: Before installing the Smart Array Multipath software on a
server with a Microsoft® operating system, connect only one of the
SCSI cables from each server to the MSA500 G2 storage system.
Leave the second SCSI cable for the redundant path disconnected until
after the multipath software is installed.
For SSP cabling configurations, refer to "SSP Hardware Configurations (on page
63 )."
Cluster cabling guidelines
To cable the cluster:
