Table 38 Information displayed by the FCQUERY command (continued)
Definition Displayed content Displayed item
Number of active Compatible FlashCopy V2 and Compatible FlashCopy SE
relationships. See the following figure. - ACT
Maximum number of pairs that can be created with the device specified by DEVN. - MAX
Volume specified by DEVN is in one of the following status. S XC
•
P-VOL of the XRC pair
•
BC Z S-VOL using At-Time Split function (online)
*
•
M-VOL of the Cnt Ac-S Z pair (Timer Type is SYSTEM or NONE, and the pair status
is Duplex or Pending Duplex)
• P-VOL of the Cnt Ac-J Z pair (Timer Type is SYSTEM or NONE, and the pair status
is Duplex or Pending Duplex)
Volume specified by DEVN is not in the status described above, or the volume is not
used. N
Volume specified by DEVN is currently used as the S-VOL (M-VOL) of the BC Z or Cnt
Ac-S Z pair. P PC
Volume specified by DEVN is currently used as the T-VOL (R-VOL) of the BC Z or Cnt
Ac-S Z pair. S
When system option mode 20 is "ON" and when the REMOTE parameter value of
the TSO command is "YES", "S" will be displayed for this item. When system option
mode 20 is "OFF", "S" will always be displayed for this item. For details about system
option mode 20, see the HP XP P9000 Continuous Access Synchronous for Mainframe
Systems User Guide.
Volume specified by DEVN is currently not used for BC Z or Cnt Ac-S Z. N
When system option mode 20 is "ON" and when the REMOTE parameter value of
the TSO command is "NO", "N" will be displayed for this item. For details about
system option mode 20, see the HP XP P9000 Continuous Access Synchronous for
Mainframe Systems User Guide.
Volume specified by DEVN is currently used as the S-VOL of the Concurrent Copy
pair. S CC
Volume specified by DEVN is currently used as the T-VOL of the Concurrent Copy
pair, or not used for Concurrent Copy. N
Displays whether the volume specified by DEVN is Revertible or not. However, since
Compatible FlashCopy does not support this function, "N" will always be displayed
for this item. For details about Revertible, see the IBM manual. - RV
The volumes specified by DEVN are TSE-VOLs. Y S SE
The volumes specified by DEVN are not TSE-VOLs. N
The volumes specified by DEVN are not source volumes of relationships containing
TSE-VOLs. N E
The volumes specified by DEVN are source volumes of relationships containing
TSE-VOLs. Y
The volumes specified by DEVN are source volumes of relationships containing
TSE-VOLs, and at least one relationship is in Failed State. F
The volumes specified by DEVN are source volumes of relationships containing
TSE-VOLs, and at least one relationship is in Write Inhibit. I
The volumes specified by DEVN are either source volumes or target volumes of
relationships containing TSE-VOLs, and there are relationships in Failed State and
Write Inhibit. B
66 Performing Compatible FlashCopy operations
