Installing Hardware Options, Hot-Pluggable
2. Squeeze upward on the release in the middle of the power supply handle (1).
3. Rotate the power supply handle downward (2) and slide the supply out of the
chassis (3) as shown in Figure 5-16.
NOTE: When you remove the power supply, a spring-loaded trap door closes to block the
opening. This door preserves the air path required to cool the internal components of the
server.
Figure 5-16: Removing a power supply
4. Remove the protective covers from the connector on the new power supply. For
more information, refer to the installation documentation that came with the
power supply. Keep the protective covers for future handling.
5. Lower the handle on the new hot-plug power supply.
5-36 HP ProLiant DL760 Generation 2 Server User Guide
