Serial and Ethernet Assignment 115
DB-9 Serial and RJ-45
Ethernet Pin Assignment
Serial and Ethernet Assignment
The pin assignments given for the DB-9 serial connection is in reference to the
serial port on the RMC in slot 1 of the Interface Manager. Use an RS-232 null
modem cable to connect the Interface Manager to the host system.See the HP
Surestore Installation and Service Guide for more information.
The pin assignments given for the RJ-45 Ethernet connection are in reference to
the Ethernet port on the RMC in slot 1of the Interface Manager. The Interface
Table 2 DB-9 Pin Assignments
Pin Number Function
Pin 1 DCD (Data Carrier Detect)
Pin 2 Receive data to the Interface Manager
Pin 3 Transmit data from the Interface Manager
Pin 4 DTR (Data Terminal Ready)
Pin 5 Ground
Pin 6 DSR (Data Set Ready)
Pin 7 RTS (Request to Send)
Pin 8 CTS (Clear to Send)
Pin 9 RI (Ring Indicator)
A
