HP Compaq t5510 Thin Client - Manual (Page 68)

5-12
Setup Menus
You can direct print data to a printer handled by the Print Manager, a specific port, or a
network printer.
Direct Print Data To The Print Manager
The Current System Printer Driver box displays the name of the currently selected
system printer when both the Use Network Printer (LPR) and Print Direct To Port
options are not selected.
Clicking the Setup button will display a Print Manager dialog box which enables you
to specify printer settings.
If you find a through print results in data being split into lines, each treated as a
separate print job, specify a time in the Seconds Close Delay box (e.g. 5 seconds).
This will enable the next line of data to be sent before the print job is assumed to have
finished and therefore prevents the print job from being closed prematurely. When set
to 0, printing will not start until a ‘print end of job’ command is received from the
host. Entering any other number will cause printing to start after the specified number
of seconds have elapsed, regardless of whether the ‘print end of job’ command has
been received from the host.
Direct Print Data To A Specific Port
To direct print data to a specific port, select Print Direct To Port and specify the
Printer Port.
Selecting the FormFeed Terminator option will cause the printer to advance the
paper to the top of the form when it has finished printing.
The Output Character Set option enables you to specify the character set used for
printing when Print Direct To Port is selected. This allows non-ISO Latin-1 printers
to be used.
Selecting Auto Line Feed will cause the printer to print at the beginning of the next
line when a carriage return command is received.
When a serial port is selected, clicking the Setup button will display a dialog box in
which you can specify the baud rate, parity, flow control, data bits and stop bits
settings. These options are described in the Serial Settings section.
