Lockstep Memory population guidelines

For Lockstep memory mode configurations, observe the following guidelines:

Observe the general DIMM slot population guidelines.

DIMM configuration on all channels of a processor must be identical.

In multi-processor configurations, each processor must have a valid Lockstep Memory

configuration.

In multi-processor configurations, each processor may have a different valid Lockstep Memory

configuration.

Population order

For memory configurations with a single processor or multiple processors, populate the DIMM slots in

the following order:

LRDIMM: Sequentially in alphabetical order (A through L)

RDIMM: Sequentially in alphabetical order (A through L)

UDIMM: A through H, sequentially in alphabetical order. Do not populate DIMM slots I through L.

HDIMM: All 12 DIMMs per processor must be populated.

After installing the DIMMs, use RBSU to configure Advanced ECC, online spare, or lockstep memory

support.

Installing a DIMM

The server supports up to 24 DIMMs. To install a DIMM:

1.

Power down the server on page 18

.

2.

Remove all power:
a.

Disconnect each power cord from the power source.

b.

Disconnect each power cord from the server.

3.

Extend the server from the rack on page 19

.

4.

Remove the access panel on page 20

.

5.

Remove the air baffle on page 28

.

6.

Open the DIMM slot latches.

Memory options 45
