Systems Insight Display LED

and color

Health LED

System power LED

Status

Over temp (amber)

Amber

Green

The Health Driver has

detected a cautionary

temperature level.

Over temp (amber)

Red

Amber

The server has detected a

hardware critical temperature

level.

PCI riser (amber)

Red

Green

The PCI riser cage is not

seated properly.

Fan (amber)

Amber

Green

One fan has failed or has

been removed.

Fan (amber)

Red

Green

Two or more fans have failed

or been removed.

Power supply (amber)

Red

Amber

One or more of the following

conditions may exist:

Only one power supply

is installed and that

power supply is in

standby.

Power supply fault

System board fault

Power supply (amber)

Amber

Green

One or more of the following

conditions may exist:

Redundant power

supply is installed and

only one power supply

is functional.

AC power cord is not

plugged into redundant

power supply.

Redundant power

supply fault

Power supply mismatch

at POST or power

supply mismatch

through hot-plug

addition

Power cap (off)

Amber

Standby

Power cap (green)

Flashing green

Waiting for power

Power cap (green)

Green

Power is available.

Power cap (flashing amber)

Amber

Power is not available.

IMPORTANT:

If more than one DIMM slot LED is illuminated, further troubleshooting is required.

Test each bank of DIMMs by removing all other DIMMs. Isolate the failed DIMM by replacing each

DIMM in a bank with a known working DIMM.
