System maintenance switch, System board components 11 – HP DL380z Gen8 Virtual Workstation User Manual

Page 17

background image

Item

Description

19

NMI jumper

20

System battery

21

SD card slot

22

Secondary (processor 2) PCI riser connector

23

System maintenance switch

24

Processor 2 socket

25

TPM connector

26

Primary (processor 1) PCI riser connector

27

FlexibleLOM

28

SAS connector 1

29

SAS connector 2

30

Cache module connector

31

Processor 1 socket

32

RDX power connector

System maintenance switch

Item

Default

Function

S1

Off

Off = HP iLO security is enabled.

On = HP iLO security is disabled.

S2

Off

Off = System configuration can be

changed.

On = System configuration is locked.

S3

Off

Reserved

S4

Off

Reserved

S5

Off

Off = Power-on password is enabled.

On = Power-on password is disabled.

S6

Off

Off = No function

On = ROM reads system configuration

as invalid.

S7

Reserved

S8

Reserved

S9

Reserved

S10

Reserved

S11

Reserved

S12

Reserved

System board components 11
