Remove the PCI riser cage

CAUTION:

To prevent damage to the server or expansion boards, power down the server and

remove all AC power cords before removing or installing the PCI riser cage.

1.

Power down the server on page 18

2.

Remove all power:
a.

Disconnect each power cord from the power source.

b.

Disconnect each power cord from the server.

3.

Extend (

Extend the server from the rack on page 19

) or remove the server from the rack.

4.

Remove the access panel on page 20

5.

Release the full-length expansion board retainer, and then remove the PCI riser cage.

6.

Remove the full-length expansion board.

Remove the PCI riser cage 25
