Item Description Status
1 Power cap Off = System is in standby, or no cap is set.
Solid green = Power cap applied
2 NIC link/activity Off = No link to network. If the power is off, view the rear panel
RJ-45 LEDs for status (" Rear panel LEDs and buttons
on page 8 ).
Flashing green = Network link and activity
Solid green = Network link
3 AMP status Off = AMP modes disabled
Solid green = AMP mode enabled
Solid amber = Failover
Flashing amber = Invalid configuration
4 Over temp Off = Normal
Solid amber = High system temperature detected
— All other LEDs Off = Normal
Amber = Failure
For more information on the activation of these LEDs, see
" Systems Insight Display LED combinations on page 5 ."
Systems Insight Display LED combinations
When the health LED on the front panel illuminates either amber or red, the server is experiencing a
health event. Combinations of illuminated Systems Insight Display LEDs, the system power LED, and
the health LED indicate system status.
Systems Insight Display LED
and color
Health LED System power LED Status
Processor (amber) Red Amber One or more of the following
conditions may exist:
● Processor in socket X
has failed.
● Processor X is not
installed in the socket.
● Processor X is
unsupported.
● ROM detects a failed
processor during POST.
Processor (amber) Amber Green Processor in socket X is in a
pre-failure condition.
DIMM (amber) Red Green One or more DIMMs have
failed.
DIMM (amber) Amber Green DIMM in slot X is in a pre-
failure condition.
Systems Insight Display LED combinations 5
