Inputs/Outputs

Digital Output Output Type

[1: Normally Open]

[2: Normally Open]

[3: Normally Open]

[4: Normally Closed]

The Output Type parameter lets you set the output switch to normally open

or normally closed If normally open is selected, the output switch is open (no

current) when the output is inactive, and closed (current flows) when the output

is active
If normally closed is selected, the output switch is closed (current flows) when

the output is inactive, and open (no current) when the output is active
To change the Output Type, follow these steps from the Inputs/Outputs main

menu:

1 Select Digital Output 1, 2, 3 or 4 and press [E] to open the Digital Output

2 From the Digital Output menu, select Output Type and press [E] to open

the Output Type display

3 Select Normally Open or Normally Closed
4 Press [E] to save the new parameter and return to the Digital Output

Hardware Type
[3: Open Collector]

[4: Open Collector]

The Hardware Type parameter lets you select the type of hardware used to drive

the output signal: either open collector or solid-state relay
To change the Hardware Type, follow these steps from the Inputs/Outputs main

menu:

1 Select Digital Output 3 or 4 and press [E] to open the Digital Output

2 From the Digital Output menu select Hardware Type, and press [E] to

open the Hardware Type display

3 Select Open Collector or Relay
4 Press [E] to save the new parameter and return to the Digital Output

Full Scale Frequency
[3: 1000 Hz]

The Full Scale Frequency parameter establishes the full scale flow output

frequency when the flow rate equals the configured full scale flow
To change the Full Scale Frequency, follow these steps from the Inputs/Outputs

main menu:

1 Select Digital Output 3 and press [E] to open the Digital Output menu
2 From the Digital Output menu select Full Scale Frequency, and press [E]

to open the Full Scale Frequency display

3 Set the full scale frequency value to the desired setting
4 Press [E] to save the new parameter and return to the Digital Output
