OPERATION
4
25
H250 M40
www.krohne.com
02/2014 - 4001208201 - AD H250 M40 FF R02 en
AI1/2_DIAG
AI 1/2
R
reason for OUT.status not Good , bits at BLK_ERR and other
diagnosis
current diagnosis
Setting:
•
Startup Device
•
RB : MODE_BLK.ACTUAL is OOS
•
Memory failure
•
no schedule
•
period of execution
•
period of execution to large
•
MODE_BLK.PERMITTED doesn’t include Auto
•
MODE_BLK.TARGET is set OOS
•
MODE_BLK.TARGET is set MAN
•
MODE_BLK.ACTUAL is MAN , Startup to Auto
•
CHANNEL is uninitialized
•
UNIT of CHANNEL selected TB.prim_val not convertible to
XD UNIT
•
XD_SCALE : difference between EU_100 and EU_0 is to less
•
OUT_SCALE : difference between EU_100 and EU_0 is to less
•
L_TYPE is uninitialized
•
L_TYPE is direct , XD_SCALE is not equal OUT_SCALE
•
IO_OPTS no unit conversion , XD UNIT doesn’t match to UNIT
of TB.prim_val
•
SIMULATE_STATUS is not Good , Simulation is active
•
SIMULATE_STATUS imited , STATUS_OPTS is set ,
Simulation active
•
Simulation is active
•
Transducer Block MODE_BLK.ACTUAL is OOS
•
CHANNEL selected TB.prim_val.status is Bad
•
TB.prim_val.status is imited , STATUS_OPTS is set
•
CHANNEL selected TB.prim_val.status is Uncertain
•
OUT.value exceeds OUT_SCALE
•
unknown reason
•
ok
PID_DIAG
PID
R
reason for OUT.status not Good , bits at BLK_ERR and other
diagnosis
current diagnosis
Setting:
•
Startup Device
•
RB : MODE_BLK.ACTUAL is OOS
•
Memory failure
•
no schedule
•
period of execution
•
period of execution to large
•
MODE_BLK.PERMITTED doesn’t include Auto
•
MODE_BLK.TARGET is set OOS
•
MODE_BLK.TARGET is set MAN
•
MODE_BLK.ACTUAL is MAN , Startup to Auto
•
BYPASS is uninitialized
•
SHED_OPT is uninitialized
•
PV_SCALE : EU_100 <= EU_0
•
OUT_SCALE : EU_100 <= EU_0
•
TRK_SCALE : EU_100 <= EU_0
•
FF_SCALE : EU_100 <= EU_0
•
unknown reason
•
ok
Manufacturer specific parameters for Resource Block
Parameter
Parameter
Parameter
Parameter
DD Name
Access
Description
Settings
Initial
