OPERATION
4
17
H250 M40
www.krohne.com 02/2014 - 4001208201 - AD H250 M40 FF R02 en
CLR_FSTATE CLR_FSTATE CLR_FSTATE CLR_FSTATE
Clear Fault State
RW Writing a "Clear" to this parameter will clear the device fault
state if the field condition, if any, has cleared.
Off
Setting:
• Uninitialized
• Off
• Clear
CONFIRM_TIME CONFIRM_TIME CONFIRM_TIME CONFIRM_TIME
Confirm Time
R/W The minimum time between retries of alert reports. 640000
Setting:
0...4294967295 in [1/32 ms]
CYCLE_SEL CYCLE_SEL CYCLE_SEL CYCLE_SEL
Cycle Selection
R/W Used to select the block execution method for this resource. Uninitialized
Setting:
• Scheduled
• Block execution
CYCLE_TYPE CYCLE_TYPE CYCLE_TYPE CYCLE_TYPE
Cycle Type
R Identifies the block execution methods available for this
resource.
• Scheduled
• Block execution
Setting:
• Scheduled
• Block execution
DD_RESOURCE DD_RESOURCE DD_RESOURCE DD_RESOURCE
DD Resource
R String identifying the tag of the resource which contains the
Device Description for this resource.
blanks
Setting:
≤ 32 digits
DD_REV DD_REV DD_REV DD_REV
DD Revision
R Revision of the DD associated with the resource - used by an
interface device to locate the DD file for the resource.
Dependent on
device Version
Setting:
Dependent on device version.
DEV_REV DEV_REV DEV_REV DEV_REV
Device Revision
R Manufacturer revision number associated with the resource -
used by an interface device to locate the DD file for the
resource.
Dependent on
device Version
Setting:
Dependent on device version.
DEV_TYPE DEV_TYPE DEV_TYPE DEV_TYPE
Device Type
R Manufacturer's model number associated with the resource -
used by interface devices to locate the DD file for the
resource.
ESK
Setting:
ESK
FAULT_STATE FAULT_STATE FAULT_STATE FAULT_STATE
Fault State
R Condition set by loss of communication to an output block,
failure promoted to an output block or a physical contact.
When fault state condition is set, then output function blocks
will perform their "FSTATE" actions.
Clear
Setting:
• Uninitialized
• Clear
• Active
FEATURES FEATURES FEATURES FEATURES
Features
R Used to show supported resource block options. • Reports
• Faultstate
• Soft W Lock
• MVC Report
• MVC Publishing
• Multi-bit Alarm
Setting:
• Reports
• Faultstate
• Soft W Lock
• MVC Report Distribution supported
• MVC Publishing/Subscribing supported
• Multi-bit Alarm (Bit-Alarm) Support
Foundation Fieldbus parameters for Resource Block
Parameter
DD Name Access Description
Settings Initial
