OPERATION
4
19
H250 M40
www.krohne.com 02/2014 - 4001208201 - AD H250 M40 FF R02 en
NV_CYCLE_T NV_CYCLE_T NV_CYCLE_T NV_CYCLE_T
Nonvolatile Cycle
Time
R Interval between writing copies of NV parameters to non-
volatile memory. Zero means never. (in [1/32 ms])
256000
RESTART RESTART RESTART RESTART
Restart
RW Allows a manual restart to be initiated. Several degrees of
restart are possible. They are 1: Run, 2: Restart resource, 3:
Restart with defaults, and 4: Restart processor.
Run
Setting:
• Uninitialized
• Run
• Resource
• Defaults
• Processor
RS_STATE RS_STATE RS_STATE RS_STATE
Resource State
R State of the function block application state machine. Standby
Setting:
• Uninitialized
• StartRestart
• Initialization
• Online Linking
• Online
• Standby
• Failure
SET_FSTATE SET_FSTATE SET_FSTATE SET_FSTATE
Set Fault State
RW Allows the fault state condition to be manually initiated by
selecting "Set".
Off
Setting:
• Uninitialized
• OFF
• SET
SHED_RCAS SHED_RCAS SHED_RCAS SHED_RCAS
Shed Remote Cascade
RW Time duration at which to give up on computer writes to
function block RCAS locations.
640000
Setting:
0...4294967295 in [1/32 ms]
SHED_ROUT SHED_ROUT SHED_ROUT SHED_ROUT
Shed Remote Out
RW Time duration at which to give up on computer writes to
function block RCAS locations.
640000
Setting:
0...4294967295 in [1/32 ms]
TEST_RW TEST_RW TEST_RW TEST_RW
Test R Write
R/write test parameter - used only for conformance testing.
Note: Subelements "1...15" have no function!
UPDATE_EVT UPDATE_EVT UPDATE_EVT UPDATE_EVT
Update Event
This alert is generated by any change to the static data.
UNACKNOWLEDGED
Unacknowledged
RW A discrete enumeration which is set to "Unacknowledged"
when an alarm occurs, and set to "Acknowledged" by a write
from a human interface device or other entity which can
acknowledge that the alarm/event has been noticed.
Uninitialized
Setting:
• Uninitialized
• Acknowledged
• Unacknowledged
UPDATE_STATE
Update State
R A discrete enumeration which gives an indication of whether
the alert has been reported.
Uninitialized
Setting:
• Uninitialized
• Reported
• Not Reported
Foundation Fieldbus parameters for Resource Block
Parameter
DD Name Access Description
Settings Initial
