6
OPERATION
64
OPTISWIRL 4070
www.krohne.com 02/2013 - 4000150606 MA OPTISWIRL4070C R07 en
3.4.13 Outlet RH
(available if Meter Type =
FAD meter, see menu
item 5.4.1, service
personnel only)
0000100.00
% Rel.Hum
↑…→↑...→↑...^
Enter relative humidity at measuring device
(compressor outlet)
3.5 Pressure, temperature and density
3.5.1 T-sensor
→
Internal temperature sensor
No ↑... No temperature sensor available
Yes ↑...^ Temperature sensor available
3.5.2 P-sensor
→
Pressure sensor
Intern ↑... Internal pressure sensor
--- ↑...^
No pressure sensor available
3.5.4 Oper. temp.
→
Operating temperature
° C
Unit ↑...^
Set temperature unit
0000000.0
°
C ^
Operating temperature
Disp. on /
Disp. off ↑...^
Display temperature /
Do not display temperature
3.5.5 Oper. press.
→
Operating pressure
Pa
Unit ↑...^
Set pressure unit
0000000.0
Pa ^
Operating pressure
Disp. on /
Disp. off ↑...^
Display pressure /
Do not display pressure
3.5.6 Oper. dens. Density at operating pressure and operating
temperature
kg/m 3
Unit ↑...^
Set density unit
00011.0000
kg/m
3 ^
Operating density
3.5.7 Temp.Norm .
(available if Maes.Inst =
Norm. Vol., see menu
item 1.1.3)
00000020.0
°
C ↑…↑...↑...^
Enter normal temperature
Unit as 3.5.4
3.5.8 Press.Norm
(available if Maes.Inst =
Norm. Vol., see menu
item 1.1.3)
00000000.0
Pa ↑…↑...↑...^
Enter normal pressure
Unit as 3.5.5
3.5.9 Dens. norm
(for unknown gases using
standard volume flow
measurement, see menu
items 1.1.3, 3.4.1 and
3.4.2)
00001.2900
kg/m
3 ^
Enter density for reference conditions (pressure and
temperature)
3.5.10 P-Excit. V
(available if P-Sensor =
Internal, see menu item
3.5.2)
0005.00000
V ^
Exciting voltage of pressure sensor
Version gas
Level Designation Selection / entry Explanation
