KROHNE OPTISWIRL 4070 EN - Manual (Page 62)

6
OPERATION
62
OPTISWIRL 4070
www.krohne.com 02/2013 - 4000150606 MA OPTISWIRL4070C R07 en
(available if Maes.Inst =
Mass, see menu item
1.1.3)
kg
Unit ↑...^
Select totalizer unit for mass flow measurement
0000000000
kg ↑…↑...↑...^
Enter preset totalizer value
Reset Yes /
Reset No ↑...^
Reset totalizer
Do not reset totalizer/
Disp. off /
Disp. on ↑...^
Do not display totalizer
Display totalizer /
3.3 HART settings
3.3.1 Poll. Addr..
→
000
0 – 15
↑…→↑...→↑...^
Enter HART polling address for "Multidrop operation"
3.3.2 HART SV
→
HART secondary variable
Total Flow ↑...
FAD ↑...^
#available if Meter
Type = FAD meter (see
menu item 5.3.1,
service personnel
only)
3.3.3 HART TV
→
HART tertiary variable
Temp. ↑..
Pressure ↑...
Density ↑...
FAD ↑...^
#available if Meter
Type = FAD meter (see
menu item 5.3.1,
service personnel
only)
3.3.4 HART 4V
→
HART quaternary variable
Temperature ↑..
Pressure ↑...
Density ↑...
FAD ↑...^
#available if Meter
Type = FAD meter (see
menu item 5.3.1,
service personnel
only)
3.4 Set fluid and medium
3.4.1 Fluid 1
→
Set fluid type
Gas ↑... Gas
Gas Mix. ↑... Gas mixture
Wet Gas ↑...^ Wet gas
1 When changing fluid: check density
Version gas
Level Designation Selection / entry Explanation
