6
OPERATION
50
OPTISWIRL 4070
www.krohne.com 02/2013 - 4000150606 MA OPTISWIRL4070C R07 en
6.5 Menu structure
6.5.1 Overview of firmware versions
There are three firmware versions, each of which is tailored to a different use of the
measuring device:
• Basic: Basic: Basic: Basic: liquids and gases without compensation, saturated steam with density compensation
using the temperature
• Steam: Steam: Steam: Steam: saturated and superheated steam with density compensation using pressure and
temperature, gross heat meter
• Gas: Gas: Gas: Gas: gas, gas mixture and wet gas with density compensation using pressure and
temperature, FAD (free air delivery measurement)
The menu structures differ from one another depending on the firmware version.
The following table contains an overview of all menu items in the first menu level. For a
complete description of the menu, note the firmware version of your measuring device and
follow the relevant instructions in the table.
Menu items Firmware version
Basic Firmware version
Steam Firmware version
Gas
1. Quick setup refer to Menu item Quick Setup on page 52
2. Tests refer to Menu item Tests on page 53
3. Setup refer to Menu item
Setup (firmware version
- basic) on page 54
refer to Menu item
Setup (firmware version
- steam) on page 57
refer to Menu item
Setup (firmware version
- gas) on page 61
5. Service The service menu is only accessible to service personnel and is not described.
Table 6-9: Overview of menu structure
INFORMATION!
The measuring device has been preset at the factory in accordance with the customer order.
Therefore, subsequent configuration via the menu is only necessary if the intended use of the
measuring device changes.
