GETTING STARTED
7
USG Series Introduction
The USG series signal and tracking generators can be operated as
standalone continuous wave generators, or when paired to a PC
and the GSP-730 spectrum analyzer, they can be used as tracking
generators.
As continuous wave generators, the USG can be configured using
any java supported PC or an Android device. The device can
generate continuous wave, sweep, power sweep and frequency
hopping waveforms.
As a tracking generator, the USG can be connected to a PC using
dedicated software (Primary RF) to synchronize the USG with the
GSP-730 spectrum analyzer.
Series lineup
The USG series consists of 5 models, spanning a number of
different frequency ranges.
Model Frequency Phase Noise
USG-LF44 34.5 MHz to 4.4 GHz < -97dBc/Hz@1GHz, 10kHz
USG-0103 100 MHz to 300 MHz < -100dBc/Hz@200MHz, 10kHz
USG-0818 800 MHz to 1.8 GHz < -97dBc/[email protected], 10kHz
USG-2030 2.0 GHz to 3.0 GHz < -93dBc/[email protected], 10kHz
USG-3044 3.0 GHz to 4.4 GHz < -88dBc/[email protected], 10kHz
Main Features
Performance  Five models supporting a frequency range from
34.5 MHz to 4.4 GHz
 10kHz resolution
 -30 dBm to 0 dBm output power
Features  Signal generator operation supports a plethora
