Appearance, Front face, Rear face – GW Instek USG-Series User Manual User Manual
Page 11
GETTING STARTED
9
Appearance
Front Face
RF output
terminal
RF Output
Terminal
RF output port. Accepts RF outputs.
Output: 0 ~ -30dBm
Input impedance: 50Ω
N-type: male
Rear Face
Mini USB port
Mini USB port
Used to connect to a PC or Android device for
configuration or control.
When connected to power, the mini USB port will
be lit red.
