USG Series User Manual

46

Spurious related to
Resolution settings
(Single Point Mode)

≤ -30 dBc, typical

Resolution < 1MHz

≤ -65 dBc, typical

Resolution ≥ 1MHz

Spurious related to the
fundamental output
(Single Point Mode)

≤ -65 dBc, typical

*: Minimum step depands on the computer being used. This min. step will be
automatically adjusted by the PC software. 1ms is achieved on a faster system.

Common Specifications

Software for PC:

a. Primary RF supports operating system: Windows 2000/XP/Vista/7/8

b. Java USG Control Panel: Windows 2000/XP/Vista/7/8 Linux/OS X

Software for mobile device:

For Android 4.0 and higher with OTG*

Interface

USB 2.0

USB Connector Type

Mini-B

Supply Voltage

5V

nominal

RF Connector Type

N-type male

Impedance

50 ohm

nominal

Output VSWR

< 1.5:1

Output level @ -30dBm

Max. DC voltage
connected to output

+/-25VDC

Max. Reverse Power

+30dBm

*Warning: Some Android devices with OTG support cannot run the USG app due
to the OTG driver modifications by vendors.
