USG Series User Manual
44
USG-0818
Frequency Range 800 MHz to 1.8 GHz
Output Power -30 dBm to 0 dBm in 1 dB steps
Internal Reference 25 MHz aging ±1 ppm at first year
Frequency Accuracy ± 800 Hz at 800MHz, 0 dBm Output
Resolution 10 kHz
Output Control On / Off
On / Off Isolation ≤ -75 dBc
Mode Control Fixed Frequency / Single Sweep / CW Sweep / Hopping
Step Dwell ≤ 1000 ms in 1* ms steps
Frequency Offset -50 kHz to 50 kHz in 10 kHz steps
Amplitude Absolute
Accuracy -0.8 dBm ± 1 dB
typical at 1000 MHz, 0 dBm Output
Output Flatness ± 1 dB, ref. to
1000MHz at 0 dBm Output
Phase noise < -97 dBc/Hz 10 kHz offset @ 1.3 GHz
< -102 dBc/Hz 100 kHz offset @ 1.3 GHz
2nd Harmonics 0 dB Attenuation
≤ -25 dBc, typical >800 MHz, fundamental
3rd Harmonics 0 dB Attenuation
≤ -25 dBc, typical ≤900 MHz, fundamental
≤ -35 dBc, typical >900 MHz, fundamental
Spurious related to
Resolution settings
(Single Point Mode) ≤ -30 dBc, typical Resolution < 1 MHz
≤ -65 dBc, typical Resolution ≥ 1 MHz
Spurious related to the
fundamental output
(Single Point Mode) ≤ -65 dBc, typical
USG-2030
Frequency Range 2.0 GHz to 3.0 GHz
Output Power -30 dBm to 0 dBm in 1 dB steps
Internal Reference 25 MHz aging ±1 ppm at first year
Frequency Accuracy ± 2 kHz at 2 GHz, 0 dBm Output
Resolution 10 kHz
Output Control On / Off
On / Off Isolation ≤ -75 dBc
Mode Control Fixed Frequency / Single Sweep / CW Sweep / Hopping
Step Dwell ≤ 1000 ms in 1* ms steps
Frequency Offset -50 kHz to 50 kHz in 10 kHz steps
