8) Z-axis intensity modulation (Real Time Mode only)
For applying a blanking signal from an external source. The trace displayed
on the screen may be intensity-modulated where pulse signal or time-scale
marks are required.
9) LED indicator and buzzer alarm
The LED’s located in the front panel assist operation and indicated
additional information. Incorrect operation and the electrical end position of
control knobs are indicated by a warning beep.
10) SMD manufacturing technology
The instrument is built by using the most advanced SMD technology so as to
reduce the number of internal wiring and shorten the foil route on the pc
board. This will also greatly increase the high frequency performance and the
reliability of the product.
11) Compact size (275W×130H×370D) mm and front panel layout groups for easy-
to-use.
GRS-6052A/6032A OSCILLOSCOPE
USER MANUAL
⎯ ⎯
5
2.TECHNICAL SPECIFICATIONS
Type
6-inch rectangular type with internal graticule;
0%, 10%, 90% and 100% markers.
8 x 10 DIV (1 DIV = 1 cm)
Accelerating Potential Approx. 10kV (GRS-6052A),
2kV (GRS-6032A)
INTEN and FOCUS Front panel control.
Illumination Provided
Trace Rotation Provided. CRT
Z-axis Input
(REAL TIME mode
only) Sensitivity: at least 5V
Polarity : positive going input decrease intensity
Usable frequency range: DC to 2MHz.
Max. input voltage: 30V (DC +AC peak) at 1kHz
or less.
Input Impedance: approx. 33kΩ(GRS-6052A)
47kΩ(GRS-6032A)
Sensitivity Accuracy 1mV~2mV/DIV ± 5%, 5mV~20V/DIV ± 3%, 14
calibrated steps in 1-2-5 sequence.
Vernier Vertical
Sensitivity Continuously variable to 1/2.5 approx. of panel
indicate value.
GRS-6052A Bandwidth(-3dB) Rise Time
5mV~20V/DIV DC~50MHz Approx. 7ns
1mV~2mV/DIV DC~7MHz Approx. 50ns
GRS-6032A Bandwidth(-3dB) Rise Time
5mV~20V/DIV DC~30MHz Approx. 11.7ns
Bandwidth(-3dB) and
Rise Time
1mV~2mV/DIV DC~7MHz Approx. 50ns
Maximum Input Voltage 400V (DC + AC peak) at 1kHz or less.
Input Coupling
AC, DC, GND
Input Impedance Approx. 1MΩ±2% // approx. 25pF
Vertical Modes CH1, CH2, DUAL(CHOP/ALT), ADD, CH2 INV.
CHOP Frequency Approx. 250kHz.
VERTICAL
SYSTEM
Dynamic Range
(REAL TIME mode
only)
GRS-6052A: 8DIV at 40MHz, 6DIV at 50MHZ
GRS-6032A: 8DIV at 20MHz, 6DIV at 30MHz
