GRS-6052A/6032A OSCILLOSCOPE
USER MANUAL
⎯ ⎯
2
1-2.Features
Additionally, the oscilloscope offers several other features:
1) High intensity and internal graticule CRT
The oscilloscope employs a high intensity 6-inch rectangular type cathode-
ray tube with red internal graticule. It displays clear readable traces even at
high sweep speeds. Internal graticule lines eliminate parallax-viewing error
between the trace and the graticule line.
2) Multiple Digital Storage Functions
z Digitizing repetitive waveform up to full bandwidth 50/30MHz through
the use of equivalent sampling (500MS/s).
z 2k-word acquisition memory per channel up to 10 sets SAVE/RECALL
reference memories (with back-up) are provided.
z Pre-trigger function for observing waveforms before triggering. The
trigger point can be selected from 0~10 DIV (in 0.02DIV steps).
z Roll mode is ideal for observing flickering low-speed signals. The
TIME/DIV range up to 100s.
z The peak detect mode can detect glitch with pulse duration of 25ns or
more.
z The persistence mode makes for easy measurements of jitter, voltage
variation, and etc.
z The averaging function can be selected freely from 2 to 256. This
effectively reduces noise from repetitive signals.
z The smoothing (dot-join) function provides linear connections between
the captured point, ensuring that digitized signals are displayed without
gaps.
z In the magnification mode, the DOT or LINEAR interpolation can be
selected according to the waveform.
GRS-6052A/6032A OSCILLOSCOPE
USER MANUAL
⎯ ⎯
3
z The built-in RS-232C interface enables remote control operation and
signal processing via a PC.
z The X-Y mode is same as the real time mode. The X (horizontal) signal is
connected to the input of CH1, the Y (vertical) signal is applied to the
input of CH2, and the storage waveform bandwidth up to 50MHz/30MHz.
3) ALT-MAG Function (both Real Time Mode and Storage Mode)
The primary sweep waveform along with the magnified sweep waveform can
be displayed simultaneously using the ALT-MAG function. The
magnification ratio can be selected from among three stages of Ч5, Ч10,
Ч20 for magnifying the displayed waveform in the center of the CRT.
4) Convenient VERT-MODE Triggering
The sync signal source is decided automatically when vertical axis mode is
switched. This means that you need not change the trigger source every time
you switch the VERT-MODE.
5) TV triggering
Exclusive TV sync separator circuit technology provides stable TV signal
measurements on fields, frames and lines.
6) Hold Off (Real Time Mode only)
The function allows the obtaining of stable synchronization for even
complex waveforms that are difficult to synchronized by adjusting the
trigger level alone.
7) CH1 Signal Output
The CH1 signal output is obtained by branching the input signal in the
middle of the signal line. As the connector outputs the input signal at a rate
of 50mV/DIV, connecting a frequency counter makes it possible to measure
the frequency of a very low signal while observing its waveform.
