GRS-6052A/6032A OSCILLOSCOPE

USER MANUAL

⎯ ⎯

This cable/appliance should be protected by a suitably rated and approved

HBC mains fuse: refer to the rating information on the equipment and/or

user instructions for details. As a guide, cable of 0.75mm

should be

protected by a 3A or 5A fuse. Larger conductors would normally require

13A types, depending on the connection method used.

Any moulded mains connector that requires removal /replacement must be

destroyed by removal of any fuse & fuse carrier and disposed of immediately,

as a plug with bared wires is hazardous if a engaged in live socket. Any re-

wiring must be carried out in accordance with the information detailed on

this label.

GRS-6052A/6032A OSCILLOSCOPE

USER MANUAL

⎯ ⎯

1.PRODUCT INTRODUCTION

1-1. Description

The GRS-6052A and GRS-6032A set a standard in performance and economy,

each equips with two professional scopes in one. They can be operated as a real

time 50 or 30MHz analog oscilloscope and become a full function digital storage

oscilloscope by pressing a button. Now, you have the power for digital capture and

analysis of elusive single shots with a full 100MS/s sample rate. The instruments

provide with a high speed A/D converter for each channel to enable the

measurement, memory, and analysis of high-speed phenomena. A microprocessor-

based operating system controls most of the functions of the instrument, including

cursor readout and digitized panel setting. On-screen alphanumeric readout and

cursor function for voltage, time and frequency measurement provide extraordinary

operational convenience. Ten different user defined instrument settings can be

saved and recalled without restriction.

The vertical deflection system has two input channels. Each channel has 14 basic

deflection factors from 1mV to 20V per division. The horizontal deflection system

provides sweep time from 100s to 0.2μs per division. The trigger system provides

stable triggering over the full bandwidth of the vertical deflection system.
