Pinouts and signaling
Pinouts and signaling
Pinout information for the front panel mini-USB console connector is provided in Table 32 .
Pinout information for the mini-USB-to-RJ-45 console cable is provided in Table 32 .
Memory specifications
The Brocade ICX 7750 has three types of memory devices: boot flash, main memory, and eUSB.
The size of each is listed in
Table 33 .
TABLE 31 Mini-USB serial console port pinout
Pin number Definition Notes
1 Not used
2 RS232 RX Console receive
3 RS232 TX Console transmit
4 Not used
5 GND Ground
TABLE 32 Mini-USB-to-RJ-45 console cable pinout
Mini-USB
pin number
Cable
connection RJ-45
pin number
Notes
2 <--------------------- 3 Console receive
3 ---------------------> 6 Console transmit
5 ---------------------- 4 Ground
1, 4 1, 2, 5, 7, 8 Not used
TABLE 33 Brocade ICX 7750 memory specifications
Type Size
Boot flash 64 MB NOR flash
Main memory - DDR3 8 GB
eUSB drive 2 GB
