Page 45: Chapter 4, Chapter 4, “managing the brocade icx 7750
Brocade ICX 7750 Hardware Installation Guide
35
53-1003084-01
Chapter
4
Managing the Brocade ICX 7750
This chapter includes these sections:
•
Hardware maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
•
Replacing a copper or fiber-optic module . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
•
FRU removal and replacement procedures . . . . . . . . . . . . . . . . . . . . . . . . . . 37
•
•
•
Replacing an expansion module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
CAUTION
The procedures in this chapter are for qualified service personnel.
CAUTION
Do not unscrew and remove the top cover of the Brocade ICX 7750. There are no
user-serviceable parts inside the Brocade ICX 7750.
Hardware maintenance schedule
Brocade ICX 7750 switch hardware components require minimal maintenance. Brocade
recommends cleaning the fiber-optic connectors on a fiber-optic port and the connected fiber cable
each time you disconnect the cable.
Replacing a copper or fiber-optic module
You can remove an SFP, SFP+, or QSFP+ transceiver from a slot and replace it with a new one while
the Brocade ICX 7750 is powered on and running.
This section provides information about the following tasks:
•
Removing a copper or fiber-optic module
•
Cleaning the fiber-optic connectors
•
Cabling a fiber-optic module
