Page 48
38
Brocade ICX 7750 Hardware Installation Guide
53-1003084-01
4
Replacing a power supply unit
The green E symbol indicates an exhaust FRU. This unit pulls air in from the front of the switch and
exhausts it out the rear side. This is called front-to-back airflow or forward airflow.
The orange I symbol indicates an intake FRU. This unit pulls air in from the rear side of the switch
and exhausts it out the front side. This is called back-to-front airflow or reverse airflow.
The show chassis command displays a device’s airflow direction: Front-to-Back or Back-to-Front.
Replacing a power supply unit
CAUTION
Remove the power cord from a power supply before you install it in or remove it from the device.
Otherwise, the power supply or the device could be damaged as a result. (The device can be
running while a power supply is being installed or removed, but the power supply itself should not
be connected to a power source.)
CAUTION
For the Brocade ICX 7750 devices, be sure that the airflow direction of the power supply unit
matches that of the installed fan tray. The power supplies and fan trays are clearly labeled with
either a green arrow with an “E”, or an orange arrow with an “I.”
ATTENTION
Maintain all power supply and fan assemblies in operational condition to provide redundancy.
CAUTION
Because the cooling system relies on pressurized air, do not leave any of the power supply and
fan assembly slots empty longer than two minutes while the switch is operating. If a power supply
or fan assembly fails, leave it in the switch until it can be replaced.
CAUTION
Disassembling any part of the power supply and fan assembly voids the warranty and regulatory
certifications. There are no user-serviceable parts inside the power supply and fan assembly.
on page 32 describes the Brocade ICX 7750 power supply status LED colors, behaviors,
and actions required, if any.
Determining the need to replace a power supply
Use one of the following methods to determine the status of the power supplies:
