46

Brocade ICX 7750 Hardware Installation Guide

53-1003084-01

A

Environmental considerations

Environmental considerations

Table 22

lists the acceptable environmental ranges for both operating and nonoperating (such as

during transportation or storage) conditions.

TABLE 21

Physical specifications Brocade ICX 7750-48C

Dimension

Value

Height

43.7 mm (1.72 in)

Depth

431 mm (16.97 in)

Width

440 mm (17.32 in)

Weight (with all power supplies, fan assemblies,
expansion module, and no transceivers installed)

10.2 kg (22.5 lb)

TABLE 22

Environmental requirements

Condition

Acceptable during operation

Acceptable during non-operation

Ambient
Temperature

ICX 7750-26Q: -5º to 50ºC (23º to 122ºF)
ICX 7750-48F: -5º to 50ºC (23º to 122ºF)
ICX 7750-48C: -5º to 40ºC (23º to 104ºF)

-40º to 60ºC (-40º to 140ºF)

Humidity

ICX 7750-26Q and ICX 7750-48F:
10% to 90% non-condensing at 50ºC (122ºF)
ICX 7750-48C:
10% to 90% non-condensing at 40ºC (104ºF)

10% to 90% non-condensing at 60ºC
(140ºF)

Altitude

0 to 3 km (9,842 feet) above sea level

12 km (39,370 feet) above sea level

Shock

20 G, 11 ms, half-sine wave

30 G, 11 ms, half-sine wave

Vibration

1 G sine, 0.4 grms random, 5-500 Hz

2.4 G sine, 1.12 grms random, 5-500 Hz

Airflow

ICX 7750-26Q:
Back-to-Front: Max. - 55 cfm, Typical - 25 cfm
Front-to-Back: Max. - 62 cfm, Typical - 29 cfm
ICX 7750-48F:
Back-to-Front: Max. - 55 cfm, Typical - 25 cfm
Front-to-Back: Max. - 61 cfm, Typical - 29 cfm
ICX 7750-48C:
Back-to-Front: Max. - 55 cfm, Typical - 32 cfm
Front-to-Back: Max. - 62 cfm, Typical - 36 cfm

N/A

Heat dissipation

ICX 7750-26Q: 833 BTU/hr
ICX 7750-48F: 764 BTU/hr
ICX 7750-48C: 1508 BTU/hr

N/A

Operating noise

ICX 7750-26Q: 62 dBA
ICX 7750-48F: 61 dBA
ICX 7750-48C: 64 dBA

N/A
