Brocade ICX 7750 Hardware Installation Guide

49

53-1003084-01

A

Power supply specifications

Power supply specifications

All units support two RPS9 redundant, load sharing, and hot-swappable power supplies.The power
supplies are universal and capable of functioning worldwide without voltage jumpers or switches.
They meet IEC 61000-4-5 surge voltage requirements and are autoranging in terms of
accommodating input voltages and line frequencies.

Table 23

lists the power state definitions for the Brocade ICX 7750.

Table 24

lists the AC power supply specifications for the Brocade ICX 7750-26Q.

Table 25

lists the AC power supply specifications for the Brocade ICX 7750-48F.

Table 26

lists the AC power supply specifications for the Brocade ICX 7750-48C.

Table 27

lists the DC power supply specifications for the Brocade ICX 7750-26Q.

TABLE 23

Power state definitions

Power state

Definition

Idle

All ports down, no optics or cables connected.

Typical

All ports linked and up. 50% traffic with 64-byte packets. Fans at normal speed.

Maximum

All ports connected with optics to draw maximum power per MSA Optics
Specification. Traffic at full rate or 100% throughput. Fans at full speed.

TABLE 24

Brocade ICX 7750-26Q AC power supply specifications

AC voltage

Input watts

BTU/hr

Power state

100-240 VAC

219

747

Idle

100-240 VAC

277

945

Typical

100-240 VAC

319

1088

Maximum

TABLE 25

Brocade ICX 7750-48F AC power supply specifications

AC voltage

Input watts

BTU/hr

Power state

100-240 VAC

144

491

Idle

100-240 VAC

254

867

Typical

100-240 VAC

290

989

Maximum

TABLE 26

Brocade ICX 7750-48C AC power supply specifications

AC voltage

Input watts

BTU/hr

Power state

100-240 VAC

244

833

Idle

100-240 VAC

510

1740

Typical

100-240 VAC

558

1904

Maximum

TABLE 27

Brocade ICX 7750-26Q DC power supply specifications

AC voltage

Input watts

BTU/hr

Power state

48 VDC

243

829

Idle
