28 Brocade ICX 7750 Hardware Installation Guide
53-1003084-01
3
Brocade ICX 7750 rear panel LEDs
The up-arrow port status LEDs for the 10 GbE ports correspond to the upper, odd-numbered ports;
the down-arrow port status LEDs correspond to the lower, even-numbered ports.
FIGURE 21 Brocade ICX 7750-48F front panel LEDs
Brocade ICX 7750 rear panel LEDs
The Brocade ICX 7750 has the following LEDs on the rear panel:
• Two Management port status LEDs
• Two HA port LEDs
• Expansion module LEDs:
• One Power LED bicolor status LED (green and amber).
• Four bicolor status LEDs (green and amber) for each of the six QSFP+ ports that indicate
the status of the ports in 40 GbE mode and 4x10 GbE breakout mode.
• Power supply LEDs. One status LED on each installed power supply.
• Fan tray LEDs. One status LED on each installed fan tray.
Figure 22 shows the LEDs on the rear panel of the Brocade ICX 7750.
1 Upper 1/10 GbE port LEDs 4 MS and DIAG status LEDs
2 Lower 1/10 GbE port LEDs 5 HA and RDNT status LEDs
3 PSU1 and PSU2 status LEDs
(PSU1 corresponds to the right power supply slot
on the back panel and PSU2 corresponds to the
left power supply slot, as viewed from the rear)
4
5
3
1 2
