12 Brocade ICX 7750 Hardware Installation Guide
53-1003084-01
2
Installation tasks
ATTENTION
You should not use tie wraps with fiber-optic cables because they are easily overtightened and can
damage the optical fibers. Velcro-like wraps are recommended.
• Plan for the rack space required for cable management before installing the switch.
• Leave at least 1 m (3.28 ft) of slack for each port cable. This provides room to remove and
replace the switch, allows for inadvertent movement of the rack, and helps prevent the cables
from being bent to less than the minimum bend radius.
• For easier maintenance, label the cables and record the devices to which they are connected.
• Keep LEDs visible by routing port cables and other cables away from the LEDs.
Installation tasks
Follow the steps listed in Table 3 to install your device. Details for each of these steps are provided
on the pages indicated.
TABLE 3 Installation tasks
Task
number Task Where to find more information
1 Ensure that the physical environment that will host the device
has the proper cabling and ventilation. “Installation and safety
considerations”
on page 10
2 If customizing a Brocade ICX 7750 baseline chassis:
1
Install at least one power supply unit.
2 Install at least three fans.
3 Install an expansion module.
“Installing and replacing a power
supply unit”
on page 19
“Installing or replacing the fan
assembly”
on page 41
“Installing or replacing an expansion
module”
on page 42
3 Install the device in an equipment rack. “Installing the device in a rack or
cabinet”
on page 14
4 Plug the device into a nearby power source that adheres to the
regulatory requirements outlined in this manual. “Powering on the system” on page 18
5 Attach a terminal or PC to the device. This will enable you to
configure the device through the command line interface (CLI). “Attaching a PC or terminal” on
page 23
6 Assign a password for additional access security. No default
password is assigned to the CLI. Brocade ICX 7750 Administration
Guide
7 Before attaching equipment to the device, you must configure
an interface IP address to the subnet on which the device will
be located. Initial IP address configuration is performed using
the CLI with a direct serial connection. Brocade ICX 7750 Administration
Guide
8 Connect network equipment to the system.
9 Test IP connectivity to other devices by pinging them and
tracing routes. Brocade ICX 7750 Administration
Guide
10 Continue configuring the device using the CLI. Brocade ICX 7750 Administration
Guide
11 Secure access to the device. Brocade ICX 7750 Administration
Guide
