Watlow EZ-ZONE ® RUI/Gateway • 3 • Chapter 1 Overview
Chapter 1: Overview
1
Features and Benefits
Remote User Interface/Gateway (RUI/GTW)
• Uses one RUI for multiple zones
• The RUI without a gateway card utilizes minimal
panel depth allowing it to fit in small spaces
• Eliminates the costs and complexity of having to
bring all controller related wires to the front
panel
• Enables the use of multiple RUIs to improve the
system’s usability and flexibility
Agency approvals: UL Listed, cULus, CSA, CE,
RoHS,
• Assures prompt product acceptance
• Reduces end product documentation costs
Short Case
• CSA C22.2 #14 Approved File 158031
• cULus UL 508 Listed approval File E102269
• UL
® 50 Type 4X, NEMA 4X indoor locations, IP65
front panel seal (indoor use only)
Long Case
• UL
® Listed to UL 61010-1 File E185611
• UL ® Reviewed to CSA C22.2 No.61010-1-04
• UL ® 50 Type 4X, NEMA 4X indoor locations, IP66
front panel seal (indoor use only)
• ODVA-EtherNet/IP™ and DeviceNet Compliance
• CSA C22.2 No. 24 File 158031 Class 4813-02
• Profibus DP
P3T Armor Sealing System
• NEMA 4X and IP65, indoor use only
• Offers water and dust resistance, can be cleaned
and washed down
Three-year warranty
• Demonstrates Watlow’s reliability and product sup-
port
EZ-Key
• Programmable EZ-Key enables simple one-touch
operation of repetitive user activities
Using the RUI/GTW as a Gateway
The addition of a gateway card allows information to
be passed from the Standard Bus side of the gateway
(EZ-ZONE ® -family controllers) to one or more of the
following popular field bus networks:
• EtherNet/IP™
• DeviceNet™
• Modbus TCP
• Modbus RTU
• Profibus DP
The networks see the gateway and RUI as separate
devices. Both sides (1 port on each side) of the gate-
way will require unique addresses based on the proto-
col specifications.
Fieldbus
Network Protocol
- EtherNet/IP
- DeviceNet
- Modbus TCP
- Modbus RTU
- Profibus DP
RUI/Gateway
Watlow
Standard
Bus
Network
PLCs
or PCs
EZ-ZONE-family
Controllers or RUIs
Note:
Excessive writes through the gateway to other EZ-
ZONE ® family controllers may cause premature
EE-PROM failure. For more detail see the section
entitled “ Saving Settings to Nonvolatile Memory .”
Note:
A Standard Bus network can communicate with a
maximum of eight RUIs with up to four of those
being gateways. Valid Standard Bus addresses for
RUIs equipped with the gateway option are 1, 2, 3
or 4. As is always the case each RUI must have a
unique Standard Bus address.
