Watlow EZ-ZONE ® RUI/Gateway • 16 • Chapter 3 Keys and Displays
EZ-ZONE PM Express Home Page
Custom
Menu
Number
Home
Page
Display
(defaults)
Parameter
Name
Custom Menu
Display
(defaults)
Parameter Page and Menu
IF 4 th digit of PN is equal to: PM _ [L] _ _ _ - _ _ _ _ B _ _ (Limit Controller)
1 Upper or
left dis-
play
(value
only)
Active Process
Value [AC;Pu]
Home Page
2 Lower or
right dis-
play
[safe]
or
[fail[
Limit State
[`l;st]
Home Page
- - - - (value
only)
Limit Low Set
Point
[`ll;s]
Operations Page
- - - - (value
only)
Limit High Set
Point
[`lh;s]
Operations Page
- - - - (value
only)
Alarm Low Set
Point
[`a;lo]
Operations Page
- - - - (value
only)
Alarm high Set
Point
[`a;hi]
Operations Page
- - - - (value
only)
Calibration Offset
[`i;Ca]
Operations Page
IF 4 th digit of PN is equal to: PM _ [C] _ _ _ - _ _ _ _ B _ _ (PID Controller)
1 Upper or
left dis-
play
(value
only)
Active Process
Value [AC;Pu]
Home Page
2 Lower or
right dis-
play
(value
only)
Active Set Point
[AC;SP]
Home Page
- - - -
[AUt1]
Autotune - - - - Operations Menu
- - - -
[C;m1]
User Control
Mode
- - - -
Operations Menu
- - - -
[h;pb1]
Heat Proportional
Band
- - - -
Operations Menu
- - - -
[C;pb1]
Cool Proportional
Band
- - - -
Operations Menu
- - - - [`ti1] Time Integral - - - - Operations Menu
- - - - [`td1] Time Derivative - - - - Operations Menu
- - - -
[o;tb1]
Time Base Out-
put 1
- - - -
Operations Menu
- - - -
[o;tb2]
Time Base Out-
put 2
- - - -
Operations Menu
- - - -
[a;lo1]
Alarm Low Set
Point
- - - -
Operations Menu
- - - -
[a;hi1]
Alarm High Set
Point
- - - -
Operations Menu
- - - - [i;Ca1] Calibration Offset - - - - Operations Menu
