Watlow EZ-ZONE ® RUI/Gateway • 52 • Appendix
RMC CIP O to T Implicit Assemblies
Assembly
Members
Assembly
Class, Instance,
Attritbute
RM Module
Data Type
Parameter
Parameter
Class, Instance,
Attritbute
PLC
Data Type
1 0x77, 0x01, 0x01 DINT Control Loop 1, Closed Loop Set Point 0x6B, 0x01, 0x01 REAL
2 0x77, 0x01, 0x02 DINT Control Loop 2, Closed Loop Set Point 0x6B, 0x02, 0x01 REAL
3 0x77, 0x01, 0x03 DINT Control Loop 3, Closed Loop Set Point 0x6B, 0x03, 0x01 REAL
4 0x77, 0x01, 0x04 DINT Control Loop 4, Closed Loop Set Point 0x6B, 0x04, 0x01 REAL
5 0x77, 0x01, 0x05 DINT Control Loop 1, Open Loop Set Point 0x6B, 0x01, 0x02 REAL
6 0x77, 0x01, 0x06 DINT Control Loop 2, Open Loop Set Point 0x6B, 0x02, 0x02 REAL
7 0x77, 0x01, 0x07 DINT Control Loop 3, Open Loop Set Point 0x6B, 0x03, 0x02 REAL
8 0x77, 0x01, 0x08 DINT Control Loop 4, Open Loop Set Point 0x6B, 0x04, 0x02 REAL
9 0x77, 0x01, 0x09 DINT Control Loop 1, User Control Mode 0x97, 0x01, 0x02 DINT
10 0x77, 0x01, 0x0A DINT Control Loop 2, User Control Mode 0x97, 0x02, 0x02 DINT
11 0x77, 0x01, 0x0B DINT Control Loop 3, User Control Mode 0x97, 0x03, 0x02 DINT
12 0x77, 0x01, 0x0C DINT Control Loop 4, User Control Mode 0x97, 0x04, 0x02 DINT
13 0x77, 0x01, 0x0D DINT Alarm 1, Alarm High Set Point 0x6D, 0x01, 0x01 REAL
14 0x77, 0x01, 0x0E DINT Alarm 2, Alarm High Set Point 0x6D, 0x02, 0x01 REAL
15 0x77, 0x01, 0x0F DINT Alarm 3, Alarm High Set Point 0x6D, 0x03, 0x01 REAL
16 0x77, 0x01, 0x10 DINT Alarm 4, Alarm High Set Point 0x6D, 0x04, 0x01 REAL
17 0x77, 0x01, 0x11 DINT Alarm 1, Alarm Low Set Point 0x6D, 0x05, 0x01 REAL
18 0x77, 0x01, 0x12 DINT Alarm 2, Alarm Low Set Point 0x6D, 0x06, 0x01 REAL
19 0x77, 0x01, 0x13 DINT Alarm 3, Alarm Low Set Point 0x6D, 0x07, 0x01 REAL
20 0x77, 0x01, 0x14 DINT Alarm 4, Alarm Low Set Point 0x6D, 0x08, 0x01 REAL
21 0x77, 0x02, 0x15 DINT None Specified - - - - - - - -
22 0x77, 0x02, 0x16 DINT None Specified - - - - - - - -
23 0x77, 0x02, 0x17 DINT None Specified - - - - - - - -
24 0x77, 0x02, 0x18 DINT None Specified - - - - - - - -
25 0x77, 0x02, 0x19 DINT None Specified - - - - - - - -
26 0x77, 0x02, 0x1A DINT None Specified - - - - - - - -
27 0x77, 0x02, 0x1B DINT None Specified - - - - - - - -
28 0x77, 0x02, 0x1C DINT None Specified - - - - - - - -
29 0x77, 0x02, 0x1D DINT None Specified - - - - - - - -
30 0x77, 0x02, 0x1E DINT None Specified - - - - - - - -
31 0x77, 0x02, 0x1F DINT None Specified - - - - - - - -
32 0x77, 0x02, 0x20 DINT None Specified - - - - - - - -
33 0x77, 0x02, 0x21 DINT None Specified - - - - - - - -
34 0x77, 0x02, 0x22 DINT None Specified - - - - - - - -
35 0x77, 0x02, 0x23 DINT None Specified - - - - - - - -
36 0x77, 0x02, 0x24 DINT None Specified - - - - - - - -
37 0x77, 0x02, 0x25 DINT None Specified - - - - - - - -
38 0x77, 0x02, 0x26 DINT None Specified - - - - - - - -
39 0x77, 0x02, 0x27 DINT None Specified - - - - - - - -
40 0x77, 0x02, 0x28 DINT None Specified - - - - - - - -
CIP Implicit Assembly
Originator (Master) to Target ( RMC )
Note:
Although 40 members are built into this module the RUI allows for a maximum of 20.
RMC CIP Implicit Assemblies
